A-C Series

RANGE FEATURES

  • I.C based voltage and current regulation designed for VRLA batteries
  • Useable on various input voltages from 110VAC – 60Hz to 240VAC – 50Hz
  • Automatic, current sensing dual-rate charging for efficient, care-free and safe operation
  • L.E.D’s indicate ‘power on’ and ‘FAST’ and ‘FLOAT’ charging modes
  • Lightweight wall mounted plug-in design with screw type output terminals
  • Alligator clip connectors with insulated sleeves
  • UL and CE approved
Summary Image

RANGE SUMMARY

The A-C series of sealed lead acid (VRLA) battery chargers are ‘switching’ type devices which operate without the use of transformers. I.C’s control and regulate current and voltage and automatically switch from the higher fast charger voltage to the lower float voltage when batteries are very close to be fully charged. At float voltage it is safe to leave the battery connected to the charger indefinitely, making battery charging pretty much fool-proof.

Opps looks like something went wrong

X

A-C Series Chargers

Weight (Kg) (Pound)

01

Voltage

Height (mm) (inches)

01

Length (mm) (inches)

01

Width (mm) (inches)

01

PSC-6300A-C

The PSC-6300A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

6V

View PSC-6300A-C

PSC-64000A-C

The PSC-64000A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

6V

View PSC-64000A-C

PSC-6500A-C

The PSC-6500A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

6V

View PSC-6500A-C

PSC-122000A-C

The PSC-122000A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

12V

View PSC-122000A-C

PSC-12300A-C

The PSC-12300A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

12V

View PSC-12300A-C

PSC-124000A-C

The PSC-124000A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

12V

View PSC-124000A-C

PSC-12500A-C

The PSC-12500A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

12V

View PSC-12500A-C

PSC-12800A-C

The PSC-12800A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

12V

View PSC-12800A-C

PSC-241000A-C

The PSC-241000A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

24V

View PSC-241000A-C

PSC-61000A-C

The PSC-61000A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

6V

View PSC-61000A-C

PSC-1210000A-C

The PSC-1210000A-C is part of our A-C series of sealed lead acid (VRLA) switch-mode battery chargers. The A-C series chargers are switching type...

Voltage:

12V

View PSC-1210000A-C

In fast charge mode voltage goes up to 2.45V +/- 0.05V before switching, in the float mode voltage is held between 2.25 – 2.30V/cell.

The A-C series of battery chargers are ideal for cyclic applications where recharge time is critical and timely charge termination cannot be counted on. Our charger range ensures optimum battery performance and service life.

To ensure safe and efficient operation always refer to our Charger Operating Instructions.

Can’t find the right battery charger?
Our battery specification sheets and individual battery pages recommend the most suitable chargers to use with that particular model. If you are unsure as to which charger is the best for your charging application please contact us and our team of expert engineers will be more than happy to help.

We offer durable, dependable and convenient battery chargers configured and calibrated specifically for the Power Sonic range of batteries. All of our chargers meet worldwide safety standards and are UL recognized.

Read more Read less
Brochure

DOWNLOAD THE POWER SONIC PRODUCTS BROCHURE

DOWNLOAD

DOWNLOAD THE A-C SERIES SUMMARY SPECIFICATION SHEET

DOWNLOAD
