| Voltage | 614.4 |
| Stored Energy (Wh) | 61.44 |
| Cycle Life | > 8000 |
| AC Input Voltage Range (VAC) | <10ms |
| Transfer Time | <10ms |
| AC Voltage Regulation | <75 dB |
| Noise Level (dB) | <75 dB |
| Operating Humidity | 5% - 85% without condensation |
| Power Factor | 0.8 leading ~ 0.8 lagging |
| THDI | ≤3% |
| Network Connectivity | Ethernet, 4G, Wi-Fi |
| Battery Chemistry | LiFePO4 |
| Fire Fighting System | Yes |
| Energy Management System | Included |
| Minimum Weight (kg) | 1050.0 |
| Minimum Weight (lbs) | 2315.0 |
| Length (in) | 37.4 |
| Length (mm) | 950.0 |
| Width (in) | 29.5 |
| Width (mm) | 750.0 |
| Height (in) | 89.7 |
| Height (mm) | 2280.0 |
| Characteristic | ES50A61G7YYCXC |
|---|---|
| Active on Web US | y |
| Active on Web EMEA | y |
| MPPT Voltage Range (V) | 150-850 |
| Cooling Method | Forced air cooling |
| Supply Input | 3P + PE + N |
| Max. PV Power STC (kW) | 96.0 |
| Startup Voltage (V) | 180.0 |
| Max. Input Voltage (V) | 1000.0 |
| Max. Operating Input Current per MPPT (A) | 40.0 |
| Max. Short Circuit Current per MPPT (A) | 60.0 |
| Number of MPP Trackers | 4.0 |
| Number of PV Strings per MPPT | 8.0 |
| Max. Grid Passthrough Current 10min (A) | 152.0 |
Up to 10 times more cycles than lead acid batteries
Completely maintenance free lithium technology
Contains safe and reliable lithium iron phosphate (LiFePO4) chemistry eliminating risk of combustion due to high impact, over-charging, or short circuits
